Extruder series

Cable Extrusion Machine

Item No.: SJ
High speed Cable extrusion line has been matured for market which is suitable for PVC, PE,PU and other plastic. its capacity has achieved international advanced level. Equipping this line enables the capacity more stable, and takes less space.
Quantity
-
+
Description
Description
Product Description
Application:

High speed Cable extrusion line has been matured for market which is suitable for PVC, PE,PU and other plastic. its capacity has achieved international advanced level. Equipping this line enables the capacity more stable, and takes less space.

High speed insulation PE PVC LSZH HFFR extruder for power cable copper core sheathing and jacketing



Products produced by High speed Cable extrusion line:

High speed insulation PE PVC LSZH HFFR extruder for power cable copper core sheathing and jacketing



Main technical data:

Cable extrusion machine model 65 90 120
Conductor(mm2) 0.35- 2.5 1.0-6.0 1.5-10.0
Wire OD (mm) 1.0-4.0 1.5~7.0 2.5~8.0
Min Thickness(mm) 0.2- 1.2
Material PVC HFFR XLPE HDPE PA PU
Output PVC (kg/h) 200 400 600
Line Speed (m/min) 1200m/min
Pay Off OD (mm) 500- 630 500~630 630~800
Cooling System Single Layer Spray Trough+Multi-pass Cooling Tank
Capstan 318 double wheel 318 double wheel 318 double wheel
Take up Spool (mm) 500- 630 630- 800 1000- 1250



High speed insulation PE PVC LSZH HFFR extruder for power cable copper core sheathing and jacketing
