Application:
High speed Double-layer concentric horizontal tape wrapping machine is used for High Frequency Signal Wire, Data Transmission Wire, Power Cables, Control Cables Special wire; Nylon, Copper Foil, Mica Tape, Aluminum Foil, Swillable Tape, PPT double layer wrapping.
Main technical data:
1) Voltage: 3P 380V±10% 50Hz standard, or customized.
2) Line height: 1000mm
3) Conductor range:0.5-16mm2(1.0-5.0mm) single copper wire or stranded copper wire
4) Reel size: pay off: 400-1000
Take up: 400-1000
5) Spool tape size: OD max. 250mm, height 100mm, ID 76mm, tape width 5-16mm, thickness 0.01-0.10mm. Max. tape weight 8kg .
6) Rotating speed: Max.2680RPM, practical 2300RPM
7) Line speed: 3-50m/min, line speed= RPM * lay length /1000
8) Taping overlapping rate: 0-67%, lay length 5-20mm, set on HMI, controlled by PLC.
9) Lay length tolerance: 1%
10) Tapping direction: S, Z both
Main Parts:
No. |
Item |
Quantity |
Remark |
1 |
400-1000 cantilever magnetic pay off |
1 |
|
2 |
Wire straightening device |
1 |
|
3 |
Horizontal spooler taping head |
2 |
|
4 |
500 double wheel capstan |
1 |
|
5 |
400-1000 torque type take up |
1 |
|
6 |
PLC control system |
1 |
|
