Main Technical Data:
|
Machine type |
22DW |
24DW |
26DW |
|
Inlet diameter(MM) |
2×Φ0.8mm |
Φ0.6-Φ1.4 |
Φ0.6-Φ1.6 |
|
Outlet diameter (MM) |
2×Φ0.10mm-Φ0.42mm |
Φ0.08-Φ0.5 |
Φ0.08-Φ0.5 |
|
Max. speed(MPM) |
1800 |
2500 |
2500 |
|
Max. number of drawing dies |
22 |
24 |
24 |
|
Mechanical reduction ratio |
15% |
13% |
13% |
|
Fixed-speed capstan reduction ratio |
8% |
8% |
8% |
|
Drawing capstan |
Ceramic coated |
||
|
Max. capstan dia.(MM) |
Φ242 |
Φ242 |
Φ242 |
|
Fixed-speed capstan dia.(MM) |
Φ207 |
Φ207 |
Φ207 |
|
Drawing capstan |
Ceramic coated |
||
|
Main machine power |
22KW |
15KW |
18.5KW |
|
Take-up power |
3.7KW |
3.7KW |
3.7KW |
|
Correction system |
Automatically control |
||
|
Dynamic control |
Double frequency converters control |
||
|
Transmission method |
Timing belt+ flat belt |
||
Pallet Packing, Wooden Packing, Vaccum Packing are all avaible as per your request.
Longer Warranty Period - 18 Months:
Complete After Service Support:
Factory Visit Available:
Strongger commissioning:
we understand that onsite support for commissioning is a crucial activity and hence we provide a skillful team of experienced engineers to ensure that the start-up and commissioning of our system at your plant is smooth.
Our start-up team is capable to manage and reduce unforeseen risks of performance problems and equipment failures. Our team follows standard processes to ensure that the necessary electrical, mechanical and environmental criteria have been met before commissioning.
During special period, our team can provide powerful Remote Commissioning.
Q: What can you offer me?
A: Our professional production and technical personnel can train our customers' employees and ensure the smooth production of customers. And will provide our customers with after-sales service.
Q:Could we appoint the parts brand?
A: Yes, ABB, SIEMENS, Danfoss, or theirs that you like.
Q: How long is the machine warranty?
A: Warranty period of one year (since the completion of mechanical successful commissioning at the buyer's factory)
Q: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?
A: We are Alibaba legitimate certification company (VIP),and we support payment L/C,T/T and so on to ensure your safety.
Q: Why do I choose your company?
A: We have more than 15 years of professional experience in the area of cable machinery, providing high-quality, high-security products.
We have an experienced team of skilled workers and engineers.
We can support overseas training engineers.
We can customize the design, to accept the customer's sample design.
We can provide customers with after-sales service.
