3KV One-step Silane Cross-linkable PE Insulation Compound XLPE Sheathing Material for Low-voltage Cables

Item No.: 00656
SEJ90-1-N, ESEJ90-1-M are one-step silan cross-linkable polyethylene insulation compound for low-voltage cables. They are mainly used for the insulation of low-voltage cables and control cables for 3KV and below. The maximum operating temperature is 90℃.
  • ModelSEJ90-1-N/SEJ90-1-M
  • Brand NameEASTMAC
  • Place of OriginChina
  • PortShanghai
  • Supply Ability1000 Tons Per Month
  • Payment TermsL/C,T/T
  • More Less
    Description
    Description

    Application:

    SEJ90-1-N, ESEJ90-1-M are one-step silan cross-linkable polyethylene insulation compound for low-voltage cables. They are mainly used for the insulation

    of low-voltage cables and control cables for 3KV and below. The maximum operating temperature is 90℃.

    Processing Indicator

    Recommend to process with the PE extruder.

    Main technical data:

    Model



    Machine Barrel Temperature

    Molding Temprature



    SEJ90-1-N

    SEJ90-1-M



    160-200℃



    215-220℃

    Item



    Unit



    Technical requirements

    Density



    g/cm3

    0.922±0.005

    Tensile Strength



    MPa

    ≥13.5

    Elongation at Break



    %

    ≥350

    Brittle Temperature with Low Temperature



    -76

    ≤15/30

    20 Volume Resistivity



    Ω·m

    ≥1.0×1014

    20 Dielectric Strength,50Hz



    MV/m

    ≥25.0

    20 Dielectric Constant,50Hz



    ----

    ≤2.35



    Air Aging Condition

    135±2×168h

    Tensile Strength

    Variation After Aging





    %



    ±20

    Elongation Variation

    After Aging





    %



    ±20



    Hot Set Test

    Condition

    200

    ×0.2MPa×15min





    1mm thick 95

    boiled 2 hours test

    1mm



    Hot Elongation



    %



    ≤100

    Permanent

    Deformation after Cooling





    %



    ≤5
