Application:
Intermedaite Wire Drawing machine is drawing bare copper wire and copper-clad aluminum wire.
Main Technical Data:
| machine type | 17DS |
| inlet diameter(mm) | φ2.5-φ3.5 |
| outlet diameter(mm) | φ0.4-φ2.0 |
| drawing line speed(MPM) | 1800 |
| drawing dies No./Max | 17 |
| slip ratio of m/c | 20% |
| fix speed capstan slip ratio | 15% |
| capstan | |
| capstan dia.(max.)(mm) | φ250 |
| fix speed capstan(mm) | φ250 |
| frame | ironed cast |
| main motor | 55KW three phase inductor motor |
| spooler motor | 15KW three phase inductor motor |
| revise system | PID synchronous spooler |
| inverter control | Dual inverter control |
| transmission type | transmits by high precision gear |
| send-out method | over head |
| traversing unit | flat belt + timing motor |
| rension control | pneumatic balance by swing arm |
| lubrication system of wire drawing | all immerse type |
| suitable diameter of spool(mm) | 500mm 630mm |
| capacity for wire receiving(kg) | 100-400 |
| bobbin loading & unloading type | |
| brake | pneumatic brake |
| machine dimension | 2100L×1022W×995H |
| machine weight | 5100 |
