Application:
EHW90, EHW90C, EHW90A are thermoplastic low-smoke halogen-free jacketing compound, which don’t contain any heavy metal like Pb, Ba,
Cd, Cr, Sn and Sb. The properties can meet RoHS Standard. They have excellent mechanical and flame-retardant properties with temperature
resistant from -40℃to 90℃. They are mainly used for the jacketing of communication cables, control cables and power cables.
Processing Indicator
Recommend to use special screw for low-smoke halogen-free compound with L/D=20-25.
Main technical data:
|
Model
|
Machine Barrel Temperature |
Molding Temprature
|
|
EHW90/EHW90C/EHW90A |
130- 140℃ |
150-160℃ |
|
Item
|
Unit
|
Specification
|
|||
|
EHW90 |
EHW90C |
EHW90A |
|||
|
Density
|
g/cm3 |
≤1.5 |
≤1.5 |
≤1.55 |
|
|
Tensile Strength
|
MPa |
≥10 |
≥10 |
≥10 |
|
|
Elongation at Break
|
% |
≥150 |
≥150 |
≥150 |
|
|
Aging Conditions
|
/ |
110℃×240h |
|||
|
Tensile Strength Variation |
% |
±25 |
±25 |
±25 |
|
|
Elongation Variation
|
% |
±25 |
±25 |
±25 |
|
|
Thermal Deformation
|
Condition |
℃ |
90℃×6h |
||
|
Variation |
% |
≤50 |
≤50 |
≤50 |
|
|
Dielectric Strength
|
MV/m |
≥20 |
≥20 |
≥20 |
|
|
Brittle Temperature With Low Temperature Impact
|
℃ |
-40 |
-40 |
-40 |
|
|
20℃ Volume Resistivity
|
Ω.m |
≥1.0×1011 |
≥1.0×1011 |
≥1.0×1011 |
|
|
PH Value
|
/ |
≥4.3 |
≥4.3 |
≥4.3 |
|
