EPR CPE Rubber CV line for crosslinked ship cable and mining cable

Item No.: 00442
Rubber Continuous Vulcanizing Line is a special machine for the purpose of insulating, sheathing and continuous vulcanizing rubber wire and cable. The rubber materials include natural rubber, EPR, EPDM, EVA, CPE, EPOM,CR, Silicone Rubber and so on. The ca
  • ModelXJ-90/16+XJ60/14
  • Brand NameEASTMAC
  • Place of OriginChina
  • PortShanghai
  • Supply Ability10 Sets per Month
  • Payment TermsL/C, T/T, D/P, D/A
  • More Less
    Description
    Description

    Application:

    Rubber Continuous Vulcanizing Line is a special machine for the purpose of insulating, sheathing and continuous vulcanizing rubber wire and cable. The rubber materials include natural rubber, EPR, EPDM, EVA, CPE, EPOM,CR, Silicone Rubber and so on. The cable which is made by this machine can be used in mining, marine, shipboard etc.



    Main Technical Data:

    ITEM XJ-90/16 XJ-120/16 XJ-150/16 XJ-65/14+XJ-90/16 XJ-90/16+XJ-120/16 XJ-65/16+XJ-120/16+XJ-90/16 XJ-90/16+XJ-150/16+XJ-120/16
    Dia. before extruding (mm) Φ5~Φ20 Φ12~Φ50 Φ20~Φ8 Φ5~Φ30 Φ15~Φ80 Φ15~Φ80 Φ20~Φ90
    Dia. after extruding (mm) Φ30 Φ60 Φ90 Φ40 Φ90 Φ90 Φ110
    Max.extruding speed (m/min) 30 30 20 30 20 20 20
    Max. output (kg/h) 150 380 550 70+150 150+380 70+150+380 150+550+380
    Heating area 5 6 6 5+5 5+6 5+5+6 5+6+6
    P/O reel Φ1600 Φ2500 Φ2500 Φ2000 Φ2500 Φ2500 Φ2500
    T/U reel Φ2500 Φ3150 Φ3150 Φ2500 Φ3150 Φ3150 Φ3150
    Capstan type TQDV2000 TQDV2500 TQDV3000 TQDV2000 TQDV3000 TQDV3000 TQDV3000



    Main Parts:

    (1) Φ800~φ2000 Portal Type Pay off 1set
    (2) Φ800 Horizontal type accumulator 1set
    (3) Cable catcher (with guiding roller) 1set
    (4) P/O length counter (dual-wheel type) 1set
    (5) 2000 caterpillar (6 pairs of cylinder) 1set
    (6) Φ300 position dancer (guiding roller) 1set
    (7) XJ-90/16 Extruder (compelling feeding material) 1set
    (8) XJ-60/14 Extruder (compelling feeding material) 1set
    (9) Cross head (Single layer, Dual Layer, Dual color) 1 set
    (10) Temperature controlling unit 7 sets
    (11) Splice box (driven by hydraulic) 1set t
    (12) Vulcanizing pipe and supporter 1set
    (13) Position controller 1set
    (14) Water/Steam balance control system 1set
    (15) End seal box (driven by hydraulic) 1set
    (16) Air blower 1set
    (17) 2000 caterpillar (6 pairs of cylinder) 1set
    (18) Φ1000 Horizontal type accumulator 1set
    (19) 1600 helper caterpillar (4 pairs of cylinder) 1set
    (20) Diameter Gauge (Online/50mm) 1set
    (21) Spark tester (15KV, chain type) 1set
    (22) T/U length counter (dual-wheel type) 1set
    (23) Φ1250~Φ2500 portal type take up 2sets
    (24) Electrical control system 1set
    (25) Operating panel 1 set
