Structure performance:
1.1 Type Horizontal DC Annealer
1.2 Annealing wire dia. 1.2 ~ 4.0mm
1.3 Max. annealing speed 25m/s
1.4 Annealing Nickel conducting ring dia. 450 (3 rings are interchangeable)
Main Technical Data:
|
No. |
Item |
Unit |
Data |
Remark |
|
1 |
Annealing Dia. |
mm |
1.2 - 4.5 |
Copper wire |
|
2 |
Annealing speed |
m/s |
25 - 6 |
Max - Min |
|
3 |
Annealing power |
KVA |
350 |
Max. |
|
4 |
Annealing voltage |
V |
60 |
Max. |
|
5 |
Annealing current |
A |
5000 |
Max. |
|
6 |
Dia. Of contact wheel |
mm |
450 |
Max.Nickle tape groove |
|
7 |
Distance between Wire inlet center and constant speed wheel center |
mm |
740 - 895 |
Customized |
|
8 |
1# annealing belt pulley dia. (constant speed wheel for annealing) |
mm |
260 |
Nominal |
|
9 |
Pre-heating section length |
mm |
10000 ~ 13000 |
adjustable |
|
10 |
Annealing section length |
mm |
2600 |
|
|
11 |
Cooling section length |
mm |
4500 - 6000 |
adjustable |
|
12 |
Steam protection pressure |
Mpa |
3 |
|
|
13 |
Compress protection pressure |
Mpa |
1.5 |
|
|
14 |
Machine Dimension |
mm |
4250x1250x2300 |
|
|
15 |
Machine weight |
T |
5.5 |
|
