Description
Description
6”x6 bobbin
Technical Parameters:
|
Items |
Configuration parameter |
|
Type |
150 type 6 reels |
|
Max. speed |
1950r/min |
|
Front twist yarn/strand diameter |
0.1-0.5mm |
|
Twist control mode |
Swap gears |
|
Capstan wheel diameter |
Φ318mmX2 |
|
Braking method |
Hydraulic pump |
|
Twisting direction |
Left and right |
|
I-wheel inside cylinder |
Φ150mm |
|
Take-up spool |
Bobbin drawings provided by user |
|
Operation direction |
As per user’s request |
|
Equipment cover type |
Ordinary housing |
|
Main motor power |
3KW |
|
Cylinder support method |
Bearing |
