40SH Stainless Steel Wire Take-up Machine
40ST Stainless Steel Wire Take-up Machine
40BH Stainless Steel Wire Annealing Machine
Stainless Steel Wire Annealing Machine Features:
Multiple electric resistance wire heating
Precise temperature control
Group control or individual control can be take-up
Easy to operate ,high efficiency of energy saving
Main Technical Data:
|
Machine Type |
40SH |
40ST |
|
Number of wire |
40 |
40 |
|
Production diameter(mm) |
0.10-0.35/0.35-0.7 |
0.10-0.70 |
|
Wire speed(mpm) |
70-180/30-80 |
200/Max |
|
Leading method |
Reducingboxing+motor+inverter+independent stop control,10heads agroup,4sets |
Reducingboxing+motor+inverter control ,20heads in a group,2sets |
|
Tension control |
Independent control on each head with balancing weight |
Torque motor+voltage regulator |
|
Traversing method |
Reducing motor+timing belt control,5 heads a group,8 sets |
Gear+crack control,20heads a group,2 sets |
|
Take-up type |
Independent AC variable frequency motor+inverter on each head |
Torque motor on each head |
|
Machine dimension(mm) |
9500L×1850W×1900H |
10000L×1500W×2200H |
|
Machine weight(kg) |
9000 |
8000 |
