Application:
SJ90X25 is used to extrude sheathing for Normal optical cable and Micro optical cable. The line will be manufactured after the seller gets the order. 100% brand new.
1.1 Produce inner sheathing
1.2 Produce outer sheathing
1.3 The extruding materials: LDPE,MDPE,HDPE,HFFR,LSZH/PA12 and so on.
Products produced by Sheathing Machine:
Main technical data:
|
Diameter of cable core |
5-30mm |
|
Diameter of loose tube |
4-6mm |
|
Diameter of cable |
5-35mm |
|
Thickness of cable wall |
1.0-3.0mm |
|
Line structure speed |
150m/min |
|
Line production speed |
90m/min(cable dia:10mm) |
|
Additional attenuation |
0.02dB/km (1310and 1550) |
|
Extruder output |
Max280kg/h |
Main Parts:
2.1 LSP1800 Portal type rail travelling pay-off
2.2 Dancer with tension controller
2.3 Loose tube pay-off
2.4 Messenger wire pay-off
2.5 Aramid yarns stranding device
2.6 Dual Pad Metal Tape Pay-off
2.7 On-line seam welding device for Steel(Aluminum) tape
2.8 Metal Tape (steel-aluminum ) accumulator
2.9 Metal Tape (Steel-Aluminum) corrugating device
2.10Metal Tape (Steel-Aluminum) longitudinal forming device
2.11 Cable jelly filling device
2.12 Water Blocking tape pay off
2.13 Rip Cord Pay-off
2.14 SJ90×25 extruder
2.15 Cross head
2.16 Vacuum application unit
2.17 Loader and hopper compound dryer
2.18 Hot-water tank and 4m movable hot-water trough
2.19 Double-layer stainless steel cooling-water trough
2.20 Blow dryer device
2.23 Hot foil length printer
2.24 Caterpillar 800kg
2.25 Swaying beam type tension dancer for take-up
2.26 LSP1800 Portal type rail travelling take-up with traverse
2.27 Electrical control system
Packaging & Shipping
Pallet Packing, Wooden Packing, Vaccum Packing are all avaible as per your request.
Our Services
Warranty Period - 12Months:
Complete After Service Support:
Factory Visit Available:
Strongger commissioning:
we understand that onsite support for commissioning is a crucial activity and hence we provide a skillful team of experienced engineers to ensure that the start-up and commissioning of our system at your plant is smooth.
Our start-up team is capable to manage and reduce unforeseen risks of performance problems and equipment failures. Our team follows standard processes to ensure that the necessary electrical, mechanical and environmental criteria have been met before commissioning.
During special period, our team can provide powerful Remote Commissioning.
