Extruder series

High speed insulation PE PVC LSZH HFFR extruder for power cable copper core sheathing and jacketing

Item No.: 00369
High speed Cable extrusion line has been matured for market which is suitable for PVC, PE,PU and other plastic. its capacity has achieved international advanced level. Equipping this line enables the capacity more stable, and takes less space.
  • ModelSJ
  • Brand NameEASTMAC
  • Place of OriginAnhui, China
  • PortShanghai
  • Description
    Description
    Application:

    High speed Cable extrusion line has been matured for market which is suitable for PVC, PE,PU and other plastic. its capacity has achieved international advanced level. Equipping this line enables the capacity more stable, and takes less space.



    Products produced by High speed Cable extrusion line:

    High speed insulation PE PVC LSZH HFFR extruder for power cable copper core sheathing and jacketing



    Main technical data:

    Cable extrusion machine model 65 90 120
    Conductor(mm2) 0.35- 2.5 1.0-6.0 1.5-10.0
    Wire OD (mm) 1.0-4.0 1.5~7.0 2.5~8.0
    Min Thickness(mm) 0.2- 1.2
    Material PVC HFFR XLPE HDPE PA PU
    Output PVC (kg/h) 200 400 600
    Line Speed (m/min) 1200m/min
    Pay Off OD (mm) 500- 630 500~630 630~800
    Cooling System Single Layer Spray Trough+Multi-pass Cooling Tank
    Capstan 318 double wheel 318 double wheel 318 double wheel
    Take up Spool (mm) 500- 630 630- 800 1000- 1250



    High speed insulation PE PVC LSZH HFFR extruder for power cable copper core sheathing and jacketing
