Description
Description
Products produced by Aluminum Extrusion line :
Main technical data:
|
Diameter of extrusion wheel |
340mm |
|
Power of main motor |
200KW DC PIONEER |
|
Max rotating speed of main machine |
24r/min |
|
Range of speed regulation |
0-24r/min |
|
Section area of products |
5-500mm2 |
|
Outlet speed |
5-120m/min |
|
Average production capacity |
540-650kg/h |
Main Parts:
1. Pay off stand and guide roller
2. Straighter
3. Aluminum cleaning system ( Brush machine)
4. Aluminum feeding and cutting system
5. LJ350/200 continuous aluminum extrusion machine
6. LJ350/200 Products and tools cooling system
7. Hydraulic lubrication station
8. Extra HV hydraulic station
9. 2000 portal type T/U with traversing-TOP CLAMPING (including counter)
10. Electrical control system
