Irradiation Cross-linkable Low-smoke Halogen-free Flame-retardant PE Jacketing Compound XLPE Insulation Material

Item No.: 00643
TEWR125 is a kind of thermoplastic low-smoke halogen-free flame-retardant elastomeric compounds. The highest working temperature is 125℃. It has good mechanical property, electrical property, flame retardant property as well as processability.
  • ModelFEHW90/FEHW105/FEHW125/FEHW150
  • Brand NameEASTMAC
  • Place of OriginChina
  • PortShanghai
  • Supply Ability1000 Tons Per Month
  • Payment TermsL/C,T/T
  • More Less
    Description
    Description

    Application:

    FEHW90, FEHW105, FEHW125, FEHW150 are irradiation cross-linkable low-smoke halogen-free jacketing compounds, which don’t contain

    heavy metals like Pb, Ba, Cd, Cr, Sn and Sb. Their properties can well meet RoHS Standard. They have good physical and mechanical properties,

    especially good temperature-resistant performances. They are mainly used for the jacketing of communication cables, control cables and power cable.

    Processing Indicator

    Recommend to use special screw for low-smoke halogen-free compound with L/D=20-25.

    Main technical data:

    Model



    Machine Barrel Temperature

    Molding Temprature



    FEHW90/FEHW105/FEHW125/
    FEHW150

    130-140℃



    150-160℃



    Item



    Unit



    Specification



    FEHW90

    FEHW105

    FEHW125

    FEHW150

    Tensile Strength



    MPa

    ≥10

    ≥10

    ≥10

    ≥10

    Elongation at Break



    %

    ≥150

    ≥150

    ≥150

    ≥150

    Density



    g/cm3

    ≤1.5

    ≤1.5

    ≤1.45

    ≤1.45

    Dielectric Strength



    MV/m

    ≥20

    ≥20

    ≥20

    ≥20

    Aging Conditions



    /

    121×168h

    136×168h

    158×168h

    180×168h

    Tensile Strength Variation

    After Aging





    %



    ≥75



    ≥75



    ≥75



    ≥75

    Elongation Variation After Aging

    %

    ≥75

    ≥75

    ≥75

    ≥75

    Brittle Temperature With Low

    Temperature Impact







    -40



    -40



    -40



    -40

    Volume Resistivity at 20



    Ω·m

    ≥1.0×1011

    ≥1.0×1011

    ≥1.0×1011

    ≥1.0×1011
