Application:
EHLZ is a kind of flame-retardant jacketing compounds with linear low density polyethylene resin as the basic raw materials. It is mainly used
as the jacketings of communication cables and control cables which have environmental-cracking resistant and flame-retardant requirements.
The highest working temperature is 70℃.
Processing Indicator
Recommend to use single-screw extruders with L/D= 20-25.
Main technical data:
|
Model
|
Machine Barrel Temperature |
Molding Temperature
|
|
EHLZ |
150-170℃ |
170-190℃ |
|
Item
|
Unit
|
Technical requirements |
|
Tensile Strength
|
MPa |
≥13.0 |
|
Elongation at Break
|
% |
≥450 |
|
Density
|
g/cm3 |
≤1.0 |
|
Melt Index |
g/10min |
≤2.0 |
|
Yield Strength |
MPa |
≥15.5 |
|
Brittle Temperature with Low Temperature |
℃ |
≤-76 |
|
Resistance to Environmental Stress Cracking F0 |
h |
≥500 |
|
20℃ Volume Resistivity
|
Ω·m |
≥1.0×1012 |
|
20℃Dielectric Strength,50Hz |
MV/m |
≥25 |
