Application:
Polypropylene insulation compound is a kind of mixing modification compounds, which regard polypropylene resin as the basic raw material.
This product has excellent electricity property, physical and mechanical property, and high-low temperature resistant properties. It not only
can be used for the insulation of in-house communication cables, but also for the insulations of high-temperature resistant and anti-fold
situations.
Processing Indicator
Recommend to use single-screw extruders with L/D= 20-25.
Main technical data:
Model
|
Machine Barrel Temperature |
Molding Temperature
|
PJ105 |
180-220℃ |
230-245℃ |
Item
|
Unit
|
Technical requirements |
Tensile Strength
|
MPa |
21 |
Elongation at Break
|
% |
≥600 |
Density
|
g/cm3 |
≤0.91 |
Melt Flow Rate |
2.5 |
|
Brittle Temperature with Low Temperature |
℃ |
- 35 |
Elongation Variation After Aging
|
% |
±30 |
Brittle Temperature With Low Temperature Impact |
℃ |
≤-35 |
Dielectric Strength
|
MV/m |
≥35 |
20℃ Volume Resistivity
|
Ω·m |
1.6×1014 |
Dielectric Dissipation Factor
|
--- |
2.22 |
