Soft and Oil-resistant Irradiation Cross-linkable Halogen-free Elastomeric Compound XLPE Sheathing Material

Item No.: 00640
FWYR125 is a kind of soft and oil-resistant irradiation cross-linkable halogen-free elastomeric compound with the highest working temperature at 125℃. It has good mechanical property, electrical property, flame retardant property and processability
  • ModelFWYR125
  • Brand NameEASTMAC
  • Place of OriginChina
  • PortShanghai
  • Supply Ability1000 Tons Per Month
  • Payment TermsL/C,T/T
  • More Less
    Description
    Description

    Application:

    FWYR125 is a kind of soft and oil-resistant irradiation cross-linkable halogen-free elastomeric compound with the highest working temperature

    at 125℃. It has good mechanical property, electrical property, flame retardant property and processability and especially excellent for oil resistant

    and soft performances. It is specially suitalbe forthe jacketing and insulation which have strict elastomeric property requirements. It also can be

    used for other cables which have high temperature requirements.

    Processing Indicator

    Recommend to use special screw for low-smoke halogen-free compound with L/D=20-25.

    Main technical data:

    Model



    Machine Barrel Temperature

    Molding Temprature



    FWYR125

    130-150℃



    145-160℃



    Item



    Unit



    Specification



    Density



    g/cm3

    ≤1.45

    Tensile Strength



    MPa

    ≥10

    Elongation at Break



    %

    ≥180

    Aging Conditions



    /

    158×168h

    Reserved Tensile Strength



    %

    ≥70

    Reserved elongation at break



    %

    ≥70

    Dielectric Strength



    MV/m

    ≥20

    Brittle Temperature With Low Temperature Impact

    -40

    20 Volume Resistivity



    Ω. m

    ≥1.0×1011

    Oxygen Index



    %

    ≥30

    HCL Gas Evolution



    Mg/g

    ≤5.0

    PH Value



    /

    ≥4.3

    Smoke Density

     No-flame Mode

     Flame Mode





    Ds max



    ≤300

    ≤150

    Conductivity



    u S/mm

    ≤10

    Toxicity Index



    /

    ≤5.0

    Hardness



    Shore A

    80-90
