Application:
4 roller caterpillar type meter counter is used for counting the cable length, normally working together with cable stranding machine, extrusion machine, laying up machine.
Main technical data:
|
Applicable Cable Dia. |
10 - 60mm
|
|
With 4 rollers + caterpillar type, passive type. Cable will be pressed pneumatically, and pressing tension can be adjusted. |
|
|
Position limiting rollers are equipped at cable inlet and outlet. Caterpillar belt is with foam layer, which can avoid slipping,to insure precise mater counting. |
|
|
With the function of counting electrically. Signal will be got by Autonics Encoder. |
|
|
Pneumatic elements |
Airtac. |
|
Counting precision |
±3‰ |
|
Central height |
1000mm |
