Application:
Applicable for multiple strand core wire of data cable, control cable and other flexible conductor cable cabling andtwisting as well as wrapping and filling meanwhile.
Split motor control type: The cantilever twisting section and end-shaft take-up section are independently drivenby different motors. lt has a clear structure and easy to operate.
Transmission shaft and differential linkage type: Linking cantilever twisting section and end-shaft take-upsection through the transmission shaft and diferential to achieve mechanical diferential take up; Stable pitchand wide adaptability.
Equipped with front tractor type: The front tractor is controlled by an independent motor to achieve pre-twistingof the core wire. Accurate pitch control, suitable for cable production with high pitch requirements
Main technical data:
| Model | YL-630 | YL-800 | YL-1000 | YL-1250 |
| Dia.Of core wire | 0.6-3.0 mm | 0.8-6.8 mm | 1.5-7.0 mm | 1.5-7.0 mm |
| Dia.Of product | Max. 12 mm | Max. 15 mm | Max.20 mm | Max.30 mm |
| Pitch of twist | 30-250 mm | 60-300 mm | 80-350 mm | 80-450 mm |
| Twisting direction | S.or Z. | S.or Z. | S.or Z. | S.or Z. |
| Rotation Speed | Max.800 rpm | Max.680 rpm | Max. 600 rpm | Max. 400 rpm |
| Take-up bobbin | 630 mm | 800 mm | 1000 mm | 1250 mm |
Pallet Packing, Wooden Packing, Vaccum Packing are all avaible as per your request.
Warranty Period - 12Months:
After Service Support:
Factory Visit Available:
Strongger commissioning:
we understand that onsite support for commissioning is a crucial activity and hence we provide a skillful team of experienced engineers to ensure that the start-up and commissioning of our system at your plant is smooth.
Our start-up team is capable to manage and reduce unforeseen risks of performance problems and equipment failures. Our team follows standard processes to ensure that the necessary electrical, mechanical and environmental criteria have been met before commissioning.
During special period, our team can provide powerful Remote Commissioning.
Q: What can you offer me?
A: Our professional production and technical personnel can train our customers' employees and ensure the smooth production of customers. And will provide our customers with after-sales service.
Q:Could we appoint the parts brand?
A: Yes, ABB, SIEMENS, Danfoss, or theirs that you like.
Q: How long is the machine warranty?
A: Warranty period of one year (since the completion of mechanical successful commissioning at the buyer's factory)
Q: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?
A: We are Alibaba legitimate certification company (VIP),and we support payment L/C,T/T and so on to ensure your safety.
Q: Why do I choose your company?
A: We have more than 15 years of professional experience in the area of cable machinery, providing high-quality, high-security products.
We have an experienced team of skilled workers and engineers.
We can support overseas training engineers.
We can customize the design, to accept the customer's sample design.
We can provide customers with after-sales service.
